Dell P2011H Monitor - Manual (Page 8)

Electrical Specifications
Model P2011H
Video input signals
Analog RGB, 0.7 Volts +/-5%, positive polarity at 75 ohm input impedance
Digital DVI-D TMDS, 600mV for each differential line, positive polarity at 50 ohm input
impedance
Synchronization input signals
Separate horizontal and vertical synchronizations, polarity-free TTL level, SOG
(Composite SYNC on green)
AC input voltage/frequency/current 100 to 240 VAC/50 or 60 Hz + 3 Hz/1.5 A (Max.)
Inrush current
120V:30A (Max.)
240V:60A (Max.)
Physical Characteristics
Model P2011H
Connector type 15-pin D-subminiature, blue connector; DVI-D, white
connector
Signal cable type Digital: Detachable, DVI-D, Solid pins, shipped
detached from the monitor
Analog: Detachable, D-Sub, 15 pins, shipped attached
to the monitor
Dimensions (with stand)
Height (extended) 435.85 mm (17.16 inches)
Height (compressed) 315.85 mm (12.44 inches)
Width 481.17 mm (18.94 inches)
Depth 171.92 mm (6.77 inches)
Dimensions (without stand)
Height 287.57 mm (11.32 inches)
Width 481.17 mm (18.94 inches)
Depth 61.50 mm (2.42 inches)
Stand dimensions
Height (extended) 360.60 mm (14.20 inches)
Height (compressed) 240.60 mm (9.47 inches)
Width 249.92 mm (9.84 inches)
Depth 171.92 mm (6.77 inches)
Weight
Weight with packaging 5.56 kg (12.23 lb)
Weight with stand assembly and cables 4.56 kg (10.03 lb)
Weight without stand assembly
