Operating the Monitor
Dell™ E248WFP Flat Panel Monitor User's Guide
Using the Front Panel Controls
Using the On-Scree Display (OSD) Menu
Setting the Optimal Resolution
Using the Dell Soundbar (Optional)
Using the Tilt
Using the Front Panel
Use the buttons on the front of the monitor to adjust the image settings.
A
Input Source Select
Use Input Source Select button to select between two different video signals that may be connected to your monitor.
l VGA input
l DVI-D input
As you cycle through the inputs you will see the following messages to indicate currently selected input source. It may
take 1 or 2 seconds for the image to appear.
If either VGA or DVI-D input is selected and both VGA and DVI-D cables are not connected, a floating dialog box as shown
below appears.
1. Auto Detect (Analog Input)
or
1. Auto Detect (Digital Input)
2. Analog Input
or
3.Digital Input
or
or
