Electrical Specifications
Model
U2212HM
Video input signals
Analog RGB, 0.7 Volts +/- 5%, positive polarity at 75 ohm input impedance
Digital DVI-D TMDS, 600 mV for each differential line, positive polarity at 50 ohm
input impedance
DP 1.1a signal input support
Synchronization input signals
TTL levels required and separate syncs (including Trigger points), SOG (Composite
SYNC on green)
AC input
voltage/frequency/current
100 VAC to 240 VAC / 50 Hz or 60 Hz + 3 Hz / 1.5 A (Typical)
Inrush current (@25°C)
120 V : 30 A (Max.)
240 V : 60 A (Max.)
Physical Characteristics
Model
U2212HM
Connector type
15-pin D-subminiature, blue connector; DVI-D, white connector; DP, black connector
Signal cable type
Digital: Detachable, DVI-D, Solid pins, shipped detached from the monitor
Analog: Detachable, D-Sub, 15 pins, shipped detached from the monitor
Dimensions (with stand)
Height (extended)
484.5 mm (19.07 inches)
Height (compressed)
355.6 mm (14.00 inches)
Width
513.0 mm (20.20 inches)
Depth
183.3 mm (7.22 inches)
Dimensions (without stand)
Height
304.5 mm (11.99 inches)
Width
513.0 mm (20.20 inches)
Depth
59.5 mm (2.34 inches)
Stand dimensions
Height (extended)
401.2 mm (15.80 inches)
