When the Repeat One function is chosen, the display will
momentarily display “REPEAT [ONE]” in the upper left
corner of the screen. The display will return to normal
after one second if the RPT button is not pressed again.
2. Press the RPT button again to activate the Repeat All
tracks function. At the end of the last track on the CD
disc, playback will automatically resume from the first
track.
•
When the Repeat All function is chosen, the display will
momentarily display “REPEAT [ALL]” in the upper left
corner of the screen. The display will return to normal
after one second if the RPT button is not pressed again.
3. Press the RPT button a third time to deactivate the Repeat
function. The current chapter will continue to playing but
will not repeat the current chapter or restart from the first
chapter at the end of the disc.
•
When the Repeat Off function is chosen, the display will
momentarily display “REPEAT [OFF]” in the upper left
corner of the screen. The display will return to normal
after one second.
I
NSTALLATION
A
ND
W
IRING
VS715 Wiring for the 3-Pin Power Harness
OWNER’S MANUAL/INSTALLATION GUIDE
19
None
Ground (Black)
Battery (Yellow)
Ignition (Red)
1
2
3
4
1 2
3 4
To Ground
Black
Red
To Vehicle
Circuits
Ignition Switch
Battery
+
-
Yellow
Fuse (Not Supplied)
Figure 10. Wiring and pin outs for the 3-pin power harness.
