Dell S2330MX Monitor - Manual (Page 9)

17 DDC/CEC GND
18 +5V
19 Hot Plug Detect
17 TX 0 -
18 TX 0 +
19 SHLD 0 / 5
20 TX 5 -
21 TX 5 +
22 TX CLK SHLD
23 TX CLK +
24 TX CLK -
Plug and Play Capability
You can install the monitor in any Plug and Play compatible system. The monitor automatically provides the computer with its Extended Display Identification Data (EDID)
using Display Data Channel (DDC) protocols so that the system can configure itself and optimize the monitor settings. Most monitor installations are automatic. You can
select different settings if required.
Flat Panel Specifications
Model number Dell S2230MX monitor Dell S2330MX monitor
Screen type Active matrix - TFT LCD Active matrix - TFT LCD
Panel Type TN TN
Screen dimensions
54.61 cm (21.5 inches) (21.5-inch diagonal
viewable image size)
58.42 cm (23 inches) (23-inch diagonal
viewable image size)
Preset display area:
Horizontal
Vertical
476.6 mm (18.76 inches)
268.1 mm (10.56 inches)
509.18 mm (20.05 inches)
286.42 mm (11.28 inches)
Pixel pitch 0.248 mm 0.265 mm
Viewing angle:
Horizontal
Vertical
170 ° typical
160 ° typical
170 ° typical
160 ° typical
Luminance output 250 cd/m² (typical) 250 cd/m² (typical)
Contrast ratio 1000 to 1 (typical) 1000 to 1 (typical)
Dynamic Contrast Ratio 8,000,000 to 1 (typical) * 8,000,000 to 1 (typical) *
Faceplate coating Antiglare with hard-coating 3H Antiglare with hard-coating 3H
Backlight LED light bar system LED light bar system
Response Time
5 ms typical ( black to white); 2 ms typical
with overdrive (grey to grey)
5 ms typical ( black to white); 2 ms typical
with overdrive (grey to grey)
Color Depth 16.7 mil colors 16.7 mil colors
Color Gamut 82 % (typical) ** 82 % (typical) **
* Based on estimation.
** [S2230MX/S2330MX] color gamut (typical) is based on CIE1976 (82 %) and CIE1931 (72 %) test standards.
Resolution Specifications
Model number Dell S2230MX monitor Dell S2330MX monitor
Scan range
Horizontal
Vertical
30 kHz to 83 kHz (automatic)
56 Hz to 75 Hz (automatic)
30 kHz to 83 kHz (automatic)
56 Hz to 75 Hz (automatic)
Maximum preset resolution 1920 x 1080 at 60 Hz 1920 x 1080 at 60 Hz
Electrical Specifications
Model number Dell S2230MX monitor Dell S2330MX monitor
Video input signals
Analog RGB: 0.7 Volts +/- 5 %, 75 ohm input
impedance
Analog RGB: 0.7 Volts +/- 5 %, 75 ohm input
impedance
Synchronization input signals
Separate horizontal and vertical
synchronizations, polarity-free TTL level, SOG
(Composite SYNC on green)
Separate horizontal and vertical
synchronizations, polarity-free TTL level, SOG
(Composite SYNC on green)
Delta adapter ADP-40DD B: 100 VAC to 240 Delta adapter ADP-40DD B: 100 VAC to 240
