Dell

™ 7609WU RS232 Protocol Document

z

RS232 Projector Pin Assignment (Facing Projector)

z

RS232 Serial Communication Cable Pin Assignment (Facing Cable)

Š

Pin Assignments

RS232 PIN DESCRIPTION

MINI DIN-6

1

2 TXD

5

3 RXD

3

4

5 GROUND 1,

2

6

7 Not

Used

6

8 Not

Used

4

9

Note 1: The RS232 cable is not provided by Dell.

z

RS232 Protocol
Communication Settings

Command Types
To display the OSD menu and adjust the settings.

Connection Settings

Value

Baud Rate

19200 bps

Data Bits

8 bits

Parity None
Stop Bits

1 bit

Flow control

None
