15 740 Articulated Truck specifications
3418 mm
11.2'
3705 mm*
12.14'
° 70
3745 mm
12.3'
577 mm
1.8'
5734 mm
18.8'
Inside
of Body
6288 mm
20.6'
1966 mm
6.4'
1458 mm
4.7'
4244 mm
13.9'
3221 mm
10.5'
10 889 mm
35.7'
3430 mm
11.2'
3520 mm
11.5'
2687 mm
8.8'
* If equipped with a scissor tailgate.
Max-unladen over tire bulge
3239 mm
10.6'
7092 mm
23.4'
697 mm
2.3'
Turning Circle
Dimensions are for machines equipped
with 29.5R25 tires.
Turning dimensions
Steer angle — left/right 45
°
SAE turning radius 8138 mm 320.4 in
Clearance radius 8595 mm 338.4 in
Inside radius 4101 mm 161.5 in
Aisle width 5694 mm 224.2 in
Steering
Lock to Lock 4.6 seconds @ 60 rpm
Dimensions
(approximate)
Optimal Loader/Truck Pass Matching
Hydraulic Excavators 385C 365C 345D
Loader Capacity (Tonnes) – 50 min hr 954-1193 750-1100 665-805
Loader Capacity (Tons) – 50 min hr 1049-1314 825-1210 735-885
Passes 3-4 5 6
Wheel Loaders 988H 980H 972H 966H
Loader Capacity (Tonnes) – 50 min hr 565-790 590-650 490-565 400-535
Loader Capacity (Tons) – 50 min hr 625-870 650-717 540-625 440-590
Passes 3-4 4 5 5-6
An optimum system match gives you a major productivity advantage. The 740 is an excellent match for the Cat 385C, 365C and
345C Hydraulic Excavators; and 972H, 980H and 988H Wheel Loaders. This results in increased production and lower system costs
per unit of volume moved.
