Setting Up the Monitor
Dell™ 1908FP-BLK Flat Panel Monitor User's Guide
Attaching the Soundbar (optional)
Attaching the Stand
NOTE:
The stand is detached from monitor when they are shipped from the factory.
1. Remove the cover and place the monitor on it.
2. Fit the two tabs on the upper part of the stand to the groove on the back of the monitor.
3. Press the stand till it snaps into place.
Connecting Your Monitor
CAUTION:
Before you begin any of the procedures in this section, follow the
.
To connect your monitor to the computer:
1. Turn off your computer and disconnect the power cable.
2. Connect either the white (digital DVI-D) or the blue (analog VGA) display connector cable to the corresponding video port on the back of your computer. Do not
connect both cables on the same computer. Use both the cables only when they are connected to two different computers with appropriate video systems.
Connecting the White DVI Cable
