*[P2210] color gamut (typical) is based on CIE1976 (83%) and CIE1931 (72%) test standards.
Resolution Specifications
Supported Video Modes
Preset Display Modes
Electrical Specifications
Screen dimensions
22 inches (22-inch viewable
image size)
Preset display area: 473.76(H)X296.1(V)
Horizontal 473.76 mm (18.7 inches)
Vertical 296.1 mm (11.7 inches)
Pixel pitch 0.282 mm
Viewing angle
160° (vertical) typical
170° (horizontal) typical
Luminance output 250 CD/m²(typical)
Contrast ratio
1000 to 1 (typical), 10000 to 1
(typical Dynamic Contrast On)
Faceplate coating Antiglare with hard-coating 3H
Backlight 2-CCFL edgelight system
Response Time 5ms panel typical
Color depth 16.7 million colors
Color Gamut 83%*
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 56 Hz to 75 Hz (automatic)
Maximum preset resolution 1680 X 1050 at 60 Hz
Video display capabilities (DVI & DP playback) 480p, 576p, 720p, 1080p
Display Mode Horizontal Frequency (kHz) Vertical Frequency (Hz) Pixel Clock (MHz) Sync Polarity (Horizontal/Vertical)
VESA, 720 x 400 31.5 70.0 28.3 -/+
VESA, 640 x 480 31.5 60.0 25.2 -/-
VESA, 640 x 480 37.5 75.0 31.5 -/-
VESA, 800 x 600 37.9 60.3 40.0 +/+
VESA, 800 x 600 46.9 75.0 49.5 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1024 x 768 60.0 75.0 78.8 +/+
VESA, 1152 x 864 67.5 75.0 108.0 +/+
VESA, 1280 x 1024 64.0 60.0 108.0 +/+
VESA, 1280 x 1024 80.0 75.0 135.0 +/+
VESA, 1680 x 1050 65.2 60.0 146.0 -/+
Video input signals
Analog RGB, 0.7 Volts +/- 5%, positive polarity at 75 ohm input
impedance
Digital DVI-D TMDS, 600mV for each differential line, positive polarity at
50 ohm input impedance
DP 1.1a signal input support
Synchronization input signals
TTL levels required and separate syncs (including Trigger points), SOG
(Composite SYNC on green)
AC input
voltage/frequency/current
100 to 240 VAC/50 or 60 Hz + 3 Hz/1.5A (Typical)
