DP1.2 Multi-Stream Transport (MST) Techsheet
This document provides an overview of the DisplayPort 1.2 technology integrated in to
the Dell UltraSharp monitors.
High Bit-rate 2
DisplayPort 1.2 supports up to twice the bandwidth of DisplayPort 1.1a. High Bit-rate 2
(HBR2) provides up to 5.4 Gbps/lane of bandwidth, or up to 21.6 Gbps in a full four-lane
configuration. This lends itself very well to many applications that require ultra-high
bandwidth.
Multi-Stream Transport (MST)
Leveraging the micro-packet architecture of DisplayPort, DisplayPort 1.2 adds the
capability to address and drive several display devices through one DisplayPort
connector. This feature has often been referred to as daisy-chaining.
Using daisy-chainable displays or MST extends the number of monitor configurations,
displaying up to maximum of four monitors, but are subjected to the graphic card’s
capability and resolution of the monitor. It is possible to combine a monitor that has at
least one DisplayPort 1.2 connector input and output and a DP1.1a-supported monitor.
However, the monitor that supports only DP1.1a can only be connected as the last
monitor in the MST chain.
Setting DP1.1a and DP1.2 on the UltraSharp Monitor
The default setting of the monitor is DP1.1a. The user must change the setting to DP1.2
on the monitor to activate MST through OSD setting. Please refer to your user guide for
instructions. For further information on MST, please refer to AMD site
