Specifications, Panel – Dell P2314T Multi Touch Monitor with LED User Manual
Page 9

About Your Monitor 9
Specifications
Panel
P2314T
P2714T
Screen type
Active matrix - TFT LCD
Panel type
In-Plane Switching / Plane
to Line Switching
Plane to Line Switching
Viewable image:
Diagonal
58.42 cm (23 inches)
68.58 cm (27 inches)
Horizontal (active area)
509.18 mm (20.05 inches)
597.89 mm (23.54 inches)
Vertical (active area)
286.42 mm (11.28 inches)
336.31 mm (13.24 inches)
Area
145839.34 mm
2
(226.05 inch
2
)
201076.39 mm
2
(311.67 inch
2
)
Pixel pitch
0.265 mm
0.311 mm
Viewing angle:
Horizontal
178 degrees typical
Vertical
178 degrees typical
Luminance:
Panel
300 cd/m² (typical)
Monitor
270 cd/m² (typical)
Dynamic contrast ratio
8,000,000:1 (typical)
Faceplate coating
Antiglare with hard-coating 3H
Glass gloss
>30 gloss units.
NOTE: For displays with edge-to-edge design, consider
the placement of the display as the reflection of
surrounding light and bright surfaces from the glass may
cause disturbances.
Backlight
LED edgelight system
Response Time
8 ms gray-to-gray (typical)
8 ms gray-to-gray (typical)
Color depth
16.77 million colors
Color gamut (Typical)
83% (CIE1976)
NOTE: Color gamut (typical) is based on CIE1976 (83%) and
CIE1931 (72%) test standards.
