Dell P170S/P190S Flat Panel Monitor User's Guide

file:///S|/SSA_Proposal/P170S_P190S/UG/setup.htm[7/8/2011 4:49:17 PM]

1. Working from the rear of the monitor, attach the Soundbar by aligning the two slots with the two tabs along the bottom rear of the monitor.

2. Slide the Soundbar to the left until it snaps into place.

3. Connect the Soundbar with the DC power connector.

4. Insert the mini stereo plug from the rear of the Soundbar into the computer's audio output jack.

CAUTION: Do not use with any device other than the Dell Soundbar

Removing the Stand

After placing the monitor panel on a soft cloth or cushion, press and hold the stand removal button, and then remove the stand.
