2025 Flat Panel Display
User’s Guide 21
Specifications
2025 Flat Panel Monitor
Display Type 20.1 inches TFT LCD 51 cm
Viewable Image Size 20.1-inch diagonal 51 cm
Tilt
Swivel -5 to +35
o
-35 to +35
o
Face Treatment Anti-glare polarizer with
hard coating
Maximum Weight
(Unpacked) 26.1 lbs. 11.87 kg (unpacked)
Dimensions
(includes pedestal)
Height
Depth
Width
21.4 inches
8.1 inches
19.2 inches 544 mm
208 mm
488 mm
Maximum Graphics
Resolution 1600 x 1200 (60 Hz) digital input
1600 x 1200 (75 Hz) analog input
Text Mode 720 x 400
Dot Pitch 0.255 x 0.255 mm
Horizontal Frequency 30 to 94 kHz analog input
30 to 92 kHz digital input
Vertical Refresh Rate 56 to 85 Hz
