7
Smoke
8
Attach
chamber
smokestack to end of smoke
chamber by sliding stack into smokestack
receiver. While holding the smokestack in a
vertical position, tighten the 3 /8-16x3/4”
hex-head bolt i n the nut that is welded to
the smokestack receiver.
Firebox
Smokestack
Smokestack receiver
To attach damper to firebox side door, place one
onto one
. Insert the bolt into the
1/4” flat washer
1/4-20x3/4” hex-head bolt
center hole of the firebox side door, from the outside. Place the handle of the damper through the lower opening in the door
from the inside and place the center hole in the damper over the bolt. Place another
onto the bolt and secure
1/4” flat washer
with a
. Do not over-tighten lock nut. Damper should be able to move freely. Slide door latch behind door catch to
1/4” lock nut
keep firebox door closed.
Damper
Side door
Door latch
