27
SPACE FOR FIXING
The cooker can be close fitted below hotplate level. This requires a minimum
distance of 540mm between cupboard units of hotplate height.
Cupboards or walls to the side of the cooker must be 125mm away
Wall cupboards above hotplate level must also be 125mm away as shown
Where cupboards or any overhead surfaces are fitted above the cooker allow
a clearance of 500mm from the top of the grill to the underside of the overhead sur-
face.
INSTALLATION INSTRUCTIONS
125mm
MIN.
125mm
MIN.
500mm MIN
540mm MIN
COOKER HOODS
If a cooker hood is to be installed, refer to the cooker hood manufactures’ instructions regarding
fixing height.
