23 104464
OWNER’S MANUAL
PARTS LIST
CISC
CISG
* Included In Hardware Kit
KEY PART
NO. NO. DESCRIPTION QTY.
1L 104171-06 Top Grate with Screen - Left (Black Only) 1
1C 104171-05 Top Grate with Screen - Center (Black Only) 1
1R 104171-07 Top Grate with Screen - Right (Black Only) 1
2 104969-01 Bottom Door (Charcoal) 1
104969-02 Bottom Door (Forest Green) 1
3 104174-03 Stove Dropped Bottom 1
4 104970-01 One Leg (Charcoal) (4 Total Per Stove) 1
104970-02 One Leg (Forest Green) (4 Total Per Stove) 1
5 104971-01 Hardware Kit 1
5-1 * Door Hinge Step Bolt With Shoulder (1 Per Unit) 1
5-2 * Door Catch Bolt M8 x 1.25 - 55mm Long With Two M8
Hex Nuts (1 Per Unit)
1
5-3 * Bottom Floor Bolts M6 x 1 - 25mm Long With Flat Washer
And Lock Washer (4 Per Unit)
1
5-4 * Leg Attachment Stud, Headless, Slotted,
M10 x 1.5 - 40mm Long
4
6 104178-01 Back Panel Bolts M6 x 1 - 20mm Long With Flat Washer
And Lock Washer (6 Per Unit)
1
7 104968-01 Stove Back Panel (Black Only) 1
PARTS AVAILABLE — NOT SHOWN
104108-08 Touch-up Spray Paint 12 oz Can (Charcoal) 1
104108-05 Touch-up Spray Paint 12 oz Can (Forest Green) 1
This list contains replaceable parts used in your stove. For replacement parts see Parts Central on page 19
of this manual.
