WIRING GUIDE – WATER (NWHSRG)
Directions:
Step 1: Select the PCN number below which matches the PCN number on your heater.
Step 2: Choose your kW, Volts, phase, and number of circuits under your PCN number (you must know the kW and watt density
(watts/sq. in.) needs for your application).
Step 3: Note the Wiring diagram # for your selection.
Step 4: Go to Wiring Diagram sheet. Peel off the diagram that matches the # in step 3. Stick this to the inside of your electrical enclosure.**
Step 5: Peel off corresponding Volts, circuit-phase, and kW info from the Wiring Diagram sheet and stick to the designated spot on the
nameplate. (These labels will cover the maximum rating stamped on the nameplate.)
Step 6: Wire Heater according to the sticker on the inside of your electrical enclosure (from step 4).
Water Applications
Approx. Watts
Wiring
Watts-Volts Circuit-Phase (amps)
/Sq. In.
Diag. #
PCN 100010 (054-304745-001)
PCN 100327 (054-304745-301)
4.5kW - 120V
1-1Ph (38 amps)
15
#7
9.0kW - 240V
1-1Ph (38 amps)
59
#13*
9.0kW - 240V
1-3Ph (22 amps)
59
#11*
18kW - 240V
2-1Ph (2 x 38 amps)
59
#8
18kW - 240V
1-3Ph (44 amps)
59
#1
18kW - 240V
2-3Ph (2 x 22 amps)
59
#2
PCN 100028 (054-304745-002)
PCN 100343 (054-304745-302)
1.5kW - 480V
1-3Ph (4 amps)
5
#6
2.5kW - 240V
1-1Ph (11 amps)
15
#13*
2.5kW - 240V
1-3Ph (6 amps)
15
#11*
4.5kW - 240V
1-1Ph (19 amps)
15
#7
4.5kW - 240V
2-1Ph (2 x 10 amps)
15
#8
4.5kW - 240V
1-3Ph (11 amps)
15
#1
4.5kW - 240V
2-3Ph (2 x 6 amps)
15
#2
4.5kW - 480V
1-1Ph (10 amps)
15
#10
4.5kW - 480V
1-3Ph (6 amps)
15
#3
9.0kW - 480V
1-1Ph (19 amps)
59
#13*
9.0kW - 480V
1-3Ph (11 amps)
59
#11*
18kW - 480V
1-1Ph (38 amps)
59
#7
18kW - 480V
2-1Ph (2 x 19 amps)
59
#8
18kW - 480V
1-3Ph (22 amps)
59
#1
18kW - 480V
2-3Ph (2 x 11 amps)
59
#2
PCN 100036 (054-304745-003)
PCN 100351 (054-304745-303)
5.0kW - 120V
1-1Ph (42 amps)
11
#7
5.0kW - 208V
1-3Ph (14 amps)
11
#4
5.0kW - 240V
1-1Ph (21 amps)
11
#10
5.0kW - 240V
1-3Ph (13 amps)
11
#3
20kW - 240V
2-1Ph (2 x 42 amps)
80
#8
20kW - 240V
2-3Ph (2 x 25 amps)
80
#2
PCN 100044 (054-304745-004)
PCN 100360 (054-304745-404)
3.0kW - 120V
1-1Ph (25 amps)
20
#13*
3.0kW - 208V
1-3Ph (9 amps)
20
#12*
6.0kW - 120V
1-1Ph (2 x 25 amps)
20
#8
6.0kW - 208V
1-3Ph (17 amps)
20
#4
6.0kW - 208V
2-3Ph (2 x 9 amps)
20
#5
12kW - 240V
1-3Ph (29 amps)
78
#11*
24kW - 240V
3-1Ph (3 x 34 amps)
78
#9
24kW - 240V
2-3Ph (2 x 29 amps)
78
#2
* Half of the heating elements are used
** For E2, affix to sheet metal on outside of enclosure
Water Applications
Approx. Watts
Wiring
Watts-Volts Circuit-Phase (amps)
/Sq. In.
Diag. #
PCN 100079 (054-304745-005)
PCN 100378 (054-304745-305)
.5kW - 240V
1-3Ph (1.3 amps)
2
#6
.75kW - 120V
1-1Ph (7 amps)
5
#13*
.75kW - 208V
1-3Ph (2.1 amps)
5
#12*
1.5kW - 120V
1-1Ph (13 amps)
5
#7
1.5kW - 120V
2-1Ph (2 x 7 amps)
5
#8
1.5kW - 208V
1-3Ph (4.2 amps)
5
#4
1.5kW - 240V
1-1Ph (7 amps)
5
#10
1.5kW - 240V
1-3Ph (3.7 amps)
5
#3
2.25kW - 208V
1-1Ph (11 amps)
15
#13*
2.25kW - 208V
1-3Ph (7 amps)
15
#11*
3.0kW - 240V
1-1Ph (13 amps)
20
#13*
3.0kW - 240V
1-3Ph (8 amps)
20
#11*
4.5kW - 208V
1-1Ph (22 amps)
15
#7
4.5kW - 208V
2-1Ph (2 x 11 amps)
15
#8
4.5kW - 208V
1-3Ph (13 amps)
15
#1
4.5kW - 208V
2-3Ph (2 x 7 amps)
15
#2
6.0kW - 240V
1-1Ph (25 amps)
20
#7
6.0kW - 240V
2-1Ph (2 x 13 amps)
20
#8
6.0kW - 240V
1-3Ph (15 amps)
20
#1
6.0kW - 240V
2-3Ph (2 x 8 amps)
20
#2
6.0kW - 480V
1-1Ph (13 amps)
20
#10
6.0kW - 480V
1-3Ph (8 amps)
20
#3
12kW - 480V
1-1Ph (25 amps)
78
#13*
12kW - 480V
1-3Ph (15 amps)
78
#11*
24kW - 480V
2-1Ph (2 x 25 amps)
78
#8
24kW - 480V
1-3Ph (29 amps)
78
#1
24kW - 480V
2-3Ph (2 x 15 amps)
78
#2
PCN 100095 (054-304745-006)
PCN 100386 (054-304745-306)
2.5kW - 120V
1-1Ph (21 amps)
15
#7
2.5kW - 120V
2-1Ph (2 x 11 amps)
15
#8
2.5kW - 208V
1-3Ph (7 amps)
15
#4
2.5kW - 240V
1-1Ph (11 amps)
15
#10
2.5kW - 240V
1-3Ph (7 amps)
15
#3
10kW - 240V
1-1Ph (42 amps)
21
#7
10kW - 240V
2-1Ph (2 x 21 amps)
21
#8
10kW - 240V
1-3Ph (25 amps)
21
#1
10kW - 240V
2-3Ph (2 x 13 amps)
21
#2
10kW - 480V
1-1Ph (21 amps)
21
#10
10kW - 480V
1-3Ph (13 amps)
21
#3
20kW - 480V
1-1Ph (42 amps)
80
#13*
20kW - 480V
1-3Ph (25 amps)
80
#11*
40kW - 480V
2-1Ph (2 x 42 amps)
80
#8
40kW - 480V
2-3Ph (2 x 25 amps)
80
#2
