13
CONNECTION AND PREPARATION
Remove the back plate at the back of the TV as shown on the illustration
opposite. Lay the LCD TV with the screen down on a table, as it will be easier to
connect your peripheral equipment. Please take precaution not to damage the
screen.
1: RF TV port
2: PC AUDIO INPUT port
3: Left channel input port
4: Right channel input port
5: A / V video input port
6: S-VIDOE input port
7: PC signal port
8: 12V power input port
CDAX DC SCART PC IN VGA L R VIDEO S-VIDEO TUNE R
1 2 3 4 5 6 7 8
