PARTS LIST
This list contains replaceable parts used in your heater. When ordering parts, follow
the instructions listed under Replacement Parts on page 27 of this manual.
PART NUMBER FOR
KEY
18,000 Btu/Hr
28,000 Btu/Hr
NO.
CGN18TB
CGN28TB
DESCRIPTION
QTY.
1
098304-01
098304-01
Screw, #10 x 3/8"
2
2
098742-03
098742-04
Front Panel (Comfort Glow)
1
098742-07
098742-08
Front Panel (Touch’n Glow)
1
3
098197-01
098197-02
Grill Guard
1
4
098342-01
098342-01
Clip, Grill Guard
2
5
098533-01AA
098533-02AA
Bottom Glass Retainer
1
6
098260-01
098260-02
Glass Panel
1
7
098532-01AA
098532-02AA
Top Glass Retainer
1
8
M11084-26
M11084-26
Screw, #10 x 3/8"
4
9
098352-01BR
098352-02BR
Deflector Unit
1
10
098271-02
098271-02
Ignitor Cable
1
11
098249-01
098249-01
Nut, M5
2
12
099440-05
099440-05
ODS/Pilot Assembly
1
12-1
098514-01
098514-01
Thermocouple
1
12-2
098515-01
098515-01
Ignitor Electrode
1
13
099120-02
099126-02
Burner
1
14
098517-01
098517-01
3/16" Pilot Tubing
1
15
098251-02
098251-04
Injector
1
16
098250-01
098250-01
Injector Holder
1
17
098867-04
098867-04
Pressure Regulator
1
18
099553-01
099553-01
Pilot Shield
1
19
098518-01
098518-01
3/8" Outlet (Burner) Tubing
1
20
098297-03
098297-03
3/8" Inlet Tubing
1
21
098264-02
098264-02
3/8" NPT Male Connector
1
22
098276-01
098276-01
1/8" NPT Plug
1
23
098277-01
098277-01
3/8" to 1/8" NPT Bushing
1
24
098265-01
098265-01
3/8" NPT Male Elbow
1
25
098275-01
098275-01
3/8" NPT Plug
1
26
098522-03
098522-04
Thermostat Gas Valve
1
27
098530-01
098531-01
Cabinet
1
28
102445-01
102445-01
Piezo Ignitor
1
29
M11084-26
M11084-26
Screw, #10 x 3/8"
2
30
M11084-38
M11084-38
Screw, #8 x 3/8"
2
31
099066-01
099066-01
Mounting Bracket
1
PARTS AVAILABLE — NOT SHOWN
098305-01
098305-01
Control Position Label
1
100642-01
100642-01
Hardware Assembly
1
