Curtis TVD2000A - Manual (Page 17)

You can select the channel by using either button
or buttons. How to select the channel
in each way is shown below.
CH +/-
Channel number
Channel selection
CABLE
VHF
2-13
STD/HRC/IRC
14-36
(A) (W)
37-59
(AA) (WW)
60-85
(AAA) (ZZZ)
86-94
(86) (94)
95-99
(A-5) (A-1)
100-125
(100) (125)
01
(5A)
TV
VHF
2-13
UHF
14-69
CABLE Mode Direct Channel Selection
When the Antenna/Cable menu option is in the Cable position, channels
can be selected as follows:
Press the Direct Channel selection buttons to select the channel.
Antenna Mode Direct Channel Selection
When the Antenna/Cable menu option is in the Antenna position, all channels
can be instantly selected by using
2
2-9: Press 2-9 as needed.
Example, to select channel 2, press "2".
10-69: Press the 2 digits in order. If you select the channel more than 69,
the channel will not be change, it is no available.
1-9: Press 1-9 as needed. Example, to select channel 2,
press "2".
10-99: Press the 2 digits in order. Example, to select channel 32,
press "3" then "2".
100-125: Press the digital 1 button, the "1--" will appear
on the screen, then press the 2 digits of remain in order.
1
Using button
Using button on the remote control, change the channel.
Same operation is available with button on the front panel
of the main unit.
CH +/-
CH +/-
CH +/-
digits button. For example:
16
POWER TV/DVD OPEN/CLOSE
Q.VIEW INFO MUTE
1 2 3 4
5 6 7 8
9 0
CC
P.MODE
CH+
CH-
VOL
_
MENU
OK
STOP SETUP PAUSE/STEP
REV FWD PREV NEXT
D.MENU REPEAT A-B
PLAY/ENTER SLOW
ANGLE TITLE/PBC SEARCH
AUDIO
CLR
D.CALL
TV/AV
PROGRAM ZOOM
10+
VOL
+
SUBTITLE
-
TV/DTV
SAP
SLEEP
CH.LIST FAV.LIST SIZ GUIDE
NOTE:
In the DTV broadcasting, one channel sometimes broadcasts
multiple programs depending on the air time. In this case, the
main channel is called major channel and the sub channel is
called minor channel.
