JUMPER PLUG PROGRAMMING
JUMPER P8: NOT USED
This jumper is not used for any alarm options.
JUMPER P9: REMOTE CARJACK FEATURE
This jumper controls whether the anti-Carjack functions of the unit can be activated through the remote control’s Button
#2 (Unlock). Carjack protection will activate via the remote under these 3 conditions: Jumper P9 is open (removed),
Ignition is in the ON position (or driving car), and the number #2 (Unlock) button on the remote is pressed AND HELD
for 2 seconds.
TRANSMITTER PROGRAMMING
1. Turn Ignition ON, press and hold the program / override button for about 5 seconds until you hear 5 siren chirp and
the parking lights come on solid.
2. Push any transmitter and the unit will flash the lights 2-4 times (2 nd transmitter code flashes 2X and third code
flashes 3X'’ etc.).
3. The is a 10 second program window in which all present transmitter codes must be programmed. Any transmitters
not present or learned in step 2 above will be dropped form the unit’s memory.
4. Turn off Ignition.
IGN
OFF
TURN IGN. ON
5 CHIRPS
PRESS AND
HOLD BUTTON
(5 SEC.)
LIGHTS FLASH 2X FOR 2nd CODE
LIGHTS ON
SLNT
C RIME S TOPPER
AUX
PRESS ANY BUTTON
ON REMOTE OR WATCH
( " " 3X FOR 3rd CODE)
( " " 4X FOR 4th CODE)
IGN
OFF
TURN IGN. OFF
