CDVI PROMI 1000 User Manual
Page 21
21
Terminal
Signification
12
Input voltage 12VAC or DC
V
Input voltage 12VAC or DC
T
N/O contact
C
Common contact
R
N/C contact
A
N/O alarm contact
5
Remote reader red LED
3
Remote reader green LED
B
Request-to-exit input
M
Common of Push button and door
contact
E
Alarm input
1
Remote reader data
2
Remote reader buzzer
RX
RX printer
M
Common printer
DT
DTR signal printer on line
TX
TX printer
V : Varistor
