Speaker Connections

Using the Dual RCA to RCA plug,
connect the R (right) and L (left)
Speaker inputs located on the back
panel of the Dipole Unit to the
corresponding Speaker outputs on the
Subwoofer.

Using the Dipole DIN cable, connect

the DIN jack of the Dipole Unit to the
DIN jack of the Subwoofer.

For information on connections to

signal sources, refer to “System
Connection Diagram” on page 3.

Power Supply Adapter

Connections

Confirm the power switch on the
Subwoofer is in the “OFF” position.
Insert the Power Adapter’s AC plug
into an appropriate receptacle. Insert
the small DC connector into the

15V

DC IN jack on the back of the
Subwoofer.

Dolby Digital source

Connect the Dolby Digital/SPDIF
output of your signal source to the
Subwoofer’s

Dolby Digital (AC-3)

SPDIF IN jack using the SPDIF Cable
(RCA to RCA) or the Optical Cable.

Game consoles

Connect the optical output of the
game console (e.g. PlayStation 2

) to

the

Optical input with the Optical

Cable.

If the optical connection is not

available or is being utilized, use the
Stereo to Dual RCA Cable and the
Dual Female RCA Adapter to connect
to the game console’s RCA output of
the multiple A/V plug.

For devices with optical output

Connect the optical output of these
devices (e.g. CD or MiniDisc

players)

to the

Optical input with the Optical

Cable.

Note: Optical connections have
priority over coaxial (SPDIF RCA to
RCA) connections.

For all other sound cards

Use the

Tandem Audio Cable.

Connect the lime-green stereo
miniplugs from the Line Out minijack
output of your sound card to the

Line

In minijack input of the Subwoofer.
Connect the black stereo miniplugs
from the Rear Out minijack output of
your sound card (if present) to the
Rear In minijack input of the
Subwoofer.
