-4- -5-
WARNING!
SAVE THESE INSTRUCTIONS!
Refer to them often and use them to instruct others.
1. NEVER REACH INTO the Jerky Slicer.
Doing so could cause serious injury. ALWAYS
USE THE PROVIDED TONGS.
2.
KEEP FINGERS CLEAR OF THE BLADES
AT ALL TIMES. Failure to do so may result in
personal injury. The Cutting Blades/Blade
Assembly is very sharp. It is recommended
to wear Kevlar, cut resistant gloves when
handling the Blades.
3. DO NOT press or push meat into the Chute
with your fingers or any other object. Doing
so may cause personal injury and/or damage
to the unit.
4. NEVER use fingers to scrape food away
from the Jerky Slicer while the grinder is in
operation. SEVERE INJURY MAY RESULT.
5. DO NOT push the Tongs or other utensils
into the Blades.
6. NEVER LEAVE THE Jerky Slicer
UNATTENDED. Close supervision is
necessary when any appliance is used near
children. This appliance is NOT to be used by
children.
7. NEVER use any accessories or parts from
other manufacturers. Doing so will VOID YOUR
WARRANTY.
8. Thoroughly clean all parts that will come into
contact with food before using the Jerky Slicer.
Wash all parts by hand and dry thoroughly.
WARNING! Protective/cut-resistant Kevlar
gloves are recommended when handling the
blade assembly.
9. DO NOT attempt to slice meat with bones
or other hard items. Damage to the machine
will occur.
10. TIE BACK loose hair and clothing, and
roll up long sleeves before operating the
Jerky Slicer. REMOVE ties, rings, watches,
bracelets, or other jewelry before operating the
Jerky Slicer.
11.
DO NOT use the Jerky Slicer while under
the influence of drugs, medications or alcohol.
GENERAL SAFETY RULES
READ AND FULLY UNDERSTAND ALL INSTRUCTIONS
AND WARNINGS PRIOR TO USING THIS UNIT. YOUR
SAFETY IS MOST IMPORTANT! FAILURE TO COMPLY
WITH PROCEDURES AND SAFE GUARDS MAY
RESULT IN SERIOUS INJURY OR PROPERTY DAMAGE.
REMEMBER: YOUR PERSONAL SAFETY IS YOUR
RESPONSIBILITY!
ASSEMBLY INSTRUCTIONS
1. Using an Allen Wrench and Screws,
attach the Left and Right Legs to the Lower
Housing.
Figure 1
2. Connect the Left and Right Legs to the
Base using the provided Allen Wrench and
Screws.
3. Install the Chute to the Top Housing
using an Allen Wrench, Screws.
4. Insert the Blade Rack Assembly into
the Lower Housing, guiding the Drive
Shaft into the bearing journals. Make sure
the teeth of the Blade Racks are properly
meshed together.
5. Position the Top Housing onto the Lower
Housing and line up the screw holes.
6. Secure the Top Housing to the Lower
Housing using the Housing Thumbscrews.
DO NOT OVERTIGHTEN!
7. Insert the Left Comb and Right Comb
into the Top Housing.
Figure 2
NOTE: The Left Comb is marked with an
“L” on the upper portion of the Comb. The
Top Housing is marked with an “L Comb”
and “R Comb” to aid in Comb installation.
8. Install Handle onto the Blade Rack
Shaft.
9. Secure the Handle to Blade Rack Shaft
with the Handle Thumbscrew .
Figure 1
Legs
Lower
Housing
Base
Chute
Top
Housing
Blade Rack
Assembly
Blade Rack
Shaft
Figure 2
Comb
