RLL233 Issue 4 Aug 2007
Page 13
Part list of motor & gearbox(Cobra)
Item Component Part No. Item Component Part No. Item Component Part No.
1 Motor assembly (110v) RD25521 3.7 Speed controller assembly (110v) RD23330 7.7 Disk spring RD45506
1 Motor assembly (230v) RD25523 3.7 Speed controller assembly (230v) RD23343 7.8 Lock nut RD45503
2 Armature assembly (110v) RD25531 3.8 Screw RD45501 8 Gearbox assembly RD25506
2 Armature assembly (230v) RD25533 3.9 End cap RD35520 5 Gearbox housing assembly RD25515
3 Field coil & motor housing assembly (110v) RD25561 3.10 Screw RD45529 6 Inner gearplate assembly RD25514
3 Field coil & motor housing assembly (230v) RD25563 4 Motor housing assembly RD25512 7 Clutch assembly RD25507
1.1 Socket head cap screw RD45532 4.1 Motor housing RD35516 8.1 Arbor spindle RD35501
1.2 Shakeproof washer RD4092 4.2 Bush RD35532 8.2 Coolant elbow RD43324
1.3 Washer RD4205 4.3 Brush holder RD35517 8.3 Screw RD45510
2 Armature assembly (110v) RD25531 5 Gearbox housing assembly RD25515 8.4 Gear selector RD35530
2 Armature assembly (230v) RD25533 5.1 Gearbox RD35506 8.5 Bush RD45521
2.1 Bearing RD45517 5.2 Seal kit RD45508 8.6 Circlip RD45513
2.2 Armature (110v) RD35521 5.3 Bearing kit (arbor spindle) RD45511 8.7 Socket set screw RD45524
2.2 Armature (230v) RD35523 5.4 Circlip RD45512 8.8 Spring RD45516
2.3 Bearing RD45526 5.5 Bearing kit (inter pinion shaft) RD45502 8.9 Steel ball RD45515
2.4 Speed sensor RD35515 6 Inner gearplate assembly RD25514 8.10 Circlip RD45509
3 Field coil & motor housing assembly (110v) RD25561 6.1 Inner gearplate RD35511 8.11 Spring RD45514
3 Field coil & motor housing assembly (230v) RD25563 6.2 Bearing RD45522 8.12 Gear RD35507
4 Motor housing assembly RD25512 6.3 Bearing RD45507 8.13 Bush RD35514
3.1 Field coil (110v) RD35551 7 Clutch assembly RD25507 8.14 Circlip RD45518
3.1 Field coil (230v) RD35553 7.1 Interpinion shaft RD35505 8.15 Gear selector ring RD35509
3.2 Screw RD45525 7.2 Washer RD45504 8.16 Snap ring RD45519
3.3 Shakeproof washer RD4092 7.3 Thrust washer RD45505 8.17 Gear RD35512
3.4 Socket head set screw RD45527 7.4 Gear RD35503 8.18 Bush RD35508
3.5 Carbon brush RD35518 7.5 Bush RD35502 8.19 Spring RD45520
3.6 Brush cover RD35519 7.6 Washer RD35504 9 Inner cap RD35513
