80-lb. Rotary Spreader

XP Stand-On Spreader

XP Stand-On

Spreader/Sprayer

TR20 Turf Renovator

THE TANK™

Spreader/Sprayer

Engine

–

6 HP* Kawasaki

8 HP* Kawasaki

17 HP* Kawasaki

Engine series

–

Vertical OHV

Horizontal OHV

Vertical OHV

Ignition

–

Recoil start

Electric start/recoil

Recoil start

Electric start

Cylinder

–

Single

Twin

Gear reduction

5:1 ratio

–

Electric motor

–

Oil ﬁ lter

–

Yes

–

Yes

Hopper/tank width

–

10 gal. total/fender mounted

20" dethatching/seeding

–

Hopper size

80 lbs.

125 lbs.

35 lbs.

125 lbs.

Tank size

–

Dual 5-gal. tanks/independent

–

40 gal.

Tank shape

Rectangular hopper

Rectangular

Strainer

Stainless mesh screen

–

Agitation

Oscillating agitator

–

Triple jet &

oscillating agitator

Hopper/tank material

Polyethylene

Steel

Polyethylene

Frame type

Stainless steel

Stainless/welded steel

Welded steel

Frame material

1” SS tube

1" SS tube & 7-ga. steel

11-ga. painted steel

Painted steel

Drive system

Push

Hydro-Gear™ transmission

Hydraulic with

chain-driven differential

Kanzaki DUP-10 pumps &

White

wheel motors

Speeds

–

Fwd: 5 mph, Rev: 3 mph

Fwd: 2 mph, Rev: 1 mph

Fwd: 10 mph, Rev: 4 mph,

lock-in application speed

Front wheels

13” x 5.0” – 6”

13" x 6.5" – 6"

13" x 5.0" – 6"

13" x 6.5" – 6"

Rear wheels

–

18" x 6.5" – 8"

18" x 8.5" – 8"

13" x 5.0" – 6"

24" x 12" – 12"

Pump output

–

4.8-GPM, 40 psi

Pump type

–

12 VDC Flojet™ pump

–

12 VDC Flojet™ pump

Pump pressure

–

Hose size

–

25-ft. coil hose w/spot

wand

–

25-ft. coil hose

Hose material

–

PVC

–

PVC

Pressure rating (hose)

–

100 psi

–

100 psi

Length x width x height

48” x 25” x 35”

56" x 35" x 48"

31" wide overall

99" x 57" x 48"

Effective spray/spread width

–

120”

120"/108" boomless spray

–

120"

Weight

32 lbs. dry

340 lbs. dry

365 lbs. dry

290 lbs. dry

1,134 lbs. dry

Spray wand/gun

–

Spot spray wand &

3 boomless spray nozzles

–

Adj. spot spray wand &

3 section boom 5 nozzle

Warranty

†

1-year limited commercial

SPRAYERS

25 Spot

50 Poly

100 Poly

200 Poly

300 Poly

200 Compact

Engine

12 VDC

4 HP* Kawasaki

5.5 HP* Kawasaki

Engine series

–

Horizontal OHV

Ignition

–

Recoil start

Cylinder

–

Single

Gear reduction

–

6:1 direct-coupled

Tank size

25 gal.

50 gal.

100 gal.

200 gal.

300 gal.

200 gal.

Tank shape

Rectangular

Strainer

In-line SS on inlet

side of pump

Stainless steel mesh

Agitation

–

Triple jet spray

Hopper/tank material

Polyethylene

Frame type

–

Welded steel

Frame material

–

Painted steel

Pump output

4.8-GPM/40 psi

Max. 6-GPM

Max. 9.5-GPM

Pump type

Diaphragm

Twin diaphragm

3-diaphragm

Pump pressure

60 psi

Max. 275 psi

Max. 550 psi

Hose reel

–

Hannay

electric

Hannay

electric

Hannay

electric

Hannay

electric

Hannay

electric

Hose size

1/4" i.d. x 25'

3/8" i.d. x 300'

1/2" i.d. x 300'

3/8" i.d. x 400'

1/2" i.d. x 300'

Hose material

Flexcoil – PVC

PVC

PVC urethane core

Pressure rating (hose)

100 psi

300 psi

800 psi

Length x width x height

30" x 20" x 19"

54" x 19" x 26"

48" x 38" x 34"

65" x 39" x 40"

88" x 38" x 47"

62" x 40" x 40"

Weight w/o hose & reel

22 lbs. dry

125 lbs.

237 lbs.

336 lbs.

422 lbs.

330 lbs.

Weight w/hose & reel

–

200 lbs.

371 lbs.

470 lbs.

556 lbs.

454 lbs.

Spray wand/gun

Trigger jet

w/conejet nozzle

Order as needed

Warranty

†

1-year limited

commercial

1-year limited

commercial

1-year limited

commercial

1-year limited

commercial

1-year limited

commercial

1-year limited

commercial

*as rated by engine manufacturer † See your local Cub Cadet Commercial Independent Dealer for warranty details.
