Vi-7 – Century 3212 User Manual
Page 9
VI-7
REF.
NO.
PART
NO.
REQ'D
NUMBER
DESCRIPTION
REF.
NO.
PART
NO.
REQ'D
NUMBER
DESCRIPTION
Section VI - PARTS (cont'd)
RECOVERY BOOM ASSEMBLY
1
5
0300113
GREASE FITTING, 1/4"-28 STR
2
2
0300626
SHEAVE, 8"
3
2
0301533
TIE DOWN STRAP, 15"
4
2
0301642
SNAP RING, 1-1/4"
5
2
0301814
RETAINING RING, 3-1/2" EXTERNAL
6
1
0301895
GREASE FITTING, 1/8" STR
7
9.2 FT.
0301949
SYNFLEX HOSE, 3/8"
8
2
0302848
WIRE ROPE, 1/2" X 150'
9
2
0400059
SCREW, 1/4"-20 X 5/8" HEX HD CAP
10
2
0400078
SCREW, 1/4"-20 X 2" HEX HD CAP
11
4
0400103
SCREW, 5/16"-18 X 1-1/4" HEX HD CAP
12
2
0400126
SCREW, 3/8"-16 X 1" HEX HD CAP
13
2
0400147
SCREW, 3/8"-16 X 5/8" HEX HD CAP
14
4
0400149
SCREW, 3/8"-24 X 5/8" HEX HD CAP
15
12
0400181
SCREW, 1/2"-13 X 1-1/2" HEX HD CAP
16
2
0400184
SCREW, 1/2"-13 X 2-1/4" HEX HD CAP
17
4
0400260
SCREW, 5/8"-11 X 2" HEX HD CAP
18
2
0400367
NUT, 1/4"-20 HEX NYLOK
19
2
0400407
NUT, 1/2"-13 HEX
20
2
0400408
NUT, 1/2"-13 HEX NYLOK
21
4
0400421
NUT, 5/8"-11 HEX NYLOK
22
4
0400451
WASHER, 1/4" FLAT
23
2
0400452
LOCKWASHER, 1/4" HELICAL
24
4
0400463
WASHER, 5/16" FLAT
25
8
0400479
WASHER, 1.510 I.D. X 2.125 O.D. X .125
26
2
0400480
WASHER, 3/8" FLAT
27
8
0400482
LOCKWASHER, 3/8" HELICAL
28
12
0400491
LOCKWASHER, 1/2" HELICAL
29
8
0400506
WASHER, 1/2" FLAT
30
1
9012549
CONNECTOR, 3/8" TUBE X 1/8" NPT
31
1
9012552
BULKHEAD COUPLING, 1/8"
32
1
9012584
ELBOW, 1/4" NPT X 3/8" TUBE 90
33
2
9056125
RETAINING RING, 1-1/4" NOM HEAVY DUTY
34
2
806510001
FLANGE BEARING
35
2
880060002
NYLATRON PAD
36
1
897400001
FRONT PIN
37
1
897400002
REAR PIN
38
1
3012-700001
PIN, MAIN BOOM PIVOT
39
1
3012-792001
PLATE, PAD CAGE
40
1
3012-792002
PLATE, PAD CAGE
41
1
3012-793001
LUBRICATOR MOUNTING PLATE
42
4
3014-791001
WASHER PLATE, 14K
43
2
3014-792001
CABLE WING
44
2
3014-801000
PIN WELDMENT
45
2
3014-802000
PIN WELDMENT
46
1
3014-820000
BOOM WELDMENT, MAIN RECOVERY
47
1
3014-821000
BRACKET WELDMENT
48
1
3014-830000
INNER BOOM WELDMENT
49
2
3014-831000
SHEAVE WELDMENT, 3014
50
2
3014-831100
SWIVEL GUIDE WELDMENT
51
1
511-3000001
BOOM EXTENSION CYLINDER
52
2
511-4000001
CYLINDER, BOOM LIFT
53
2
514-1501101
WINCH, 15K DP
54
1
535-0500001
NYLATRON PAD
55
2
541-5050219
SCREW, 1/2"-13 X 3" HEX HD CAP FULL THRD
