30
TECHNICAL DATA
DIMENSIONS
Height
900 - 915mm
Width 538mm
Depth 595mm (excluding door handles)
GENERAL
Gas connection
Rp 1 /
2
( 1 /
2
” BSP female)
Pressure test point Grill injector
Gas rate adjustment None
Aeration adjustment None
Electrical connection Flexible cord fitted with a 3 pin 13 amp plug
230/240V a.c. 50Hz. 3A fuse.
INSTALLATION INSTRUCTIONS
HEAT
INPUT
LPG MODELS
BURNER
INJECTOR
3.9 kW GRILL 150
2.7 kW MAIN OVEN 120
2.0 kW TOP OVEN 100
3.0 kW HOTPLATE
Front left and rear right 128
1.9 kW HOTPLATE
Front right and rear left 102
HEAT
INPUT
INJECTOR
3.3 kW 95
2.4 kW 75
2.0 kW 60
3.0 kW 90
1.7 kW 71
