Page 3
RD 5200 Series
S Class
Specifications
1 Manufacturer
Crown Equipment Corporation
2 Model
RD 5275S
RD 5285S
3 Load Capacity*
Max
lb
3000
3000
4 Load Center
Fork Face to Load CG
in
24
24
5 Power
36 Volts
36 Volts
6 Operator Type
Reach
Sit/Stand
Sit/Stand
7 Tire Type
Load/Caster/Drive
Poly/Poly/Poly
8 Wheels (x = driven)
Load/Power Unit
4/2 (1x)
Mast Type
Hi-Visibility
TT
9 Lift Height
in
See Mast Chart
10 Guard Height
in
See Mast Chart
13 Forks
Standard L x W x T
in
36 x 4 x 1.5
Optional Lengths
in
30, 39, 42, 45, 48
14 Carriage
Tilt F°/B°
degree
3 / 4
15 Headlength**
Comp’t “C”
in
60.06
Comp’t “D”
in
61.81
Comp’t “E”
in
64.43 / 69.18†
17 Overall Collapsed Height
in
See Mast Chart
18 Overall Extended Height
in
See Mast Chart
20 Inside Straddle Width
In 1" increments
in
34 - 50
24 Speed Travel
Power Unit First (E/L)
mph
7.5 / 7.5
8.3 / 7.5
Forks First (E/L)
mph
6.2 / 6.2
6.7 / 6.2
24a Speed Travel -
Power Unit First (E/L)
mph
8.3 / 7.5
Std.
Max Performance System †† Forks First (E/L)
mph
6.7 / 6.2
Std.
25 Speed Lift***
Empty
fpm
131
143
1000 lb
fpm
116
125
2000 lb
fpm
103
111
3000 lb
fpm
93
99
25a High Speed Lift****
Empty/Loaded
fpm
143 / 99
Std.
26 Speed Lower
Empty/Loaded
fpm
85 / 90
110 / 90
26a Speed Lower -
Empty/Loaded
fpm
110 / 90
Std.
Max Performance System ††
37 Tires
Size - Drive/Caster
in
13 x 5.5 / 8.5 x 2.7 x (2)
38 Wheelbase (Standard Wheel) Comp’t “C”
in
61.32
Comp’t “D”
in
63.07
Comp’t “E”
in
65.70 / 70.45†
39 Suspension
Drive
Articulated
Caster
Articulated, Swivel
42 Brakes
Drive
Elec Release / Mech Applied
Caster
Electronically Applied
Parking
Elec Release / Mech Applied
Battery Removal
Drive Side
45
Type
Lead Acid
46
Min Weight/Max Amp
Comp’t “C”
lb/amp
2000 / 930
2000 / 930
Comp’t “D”
lb/amp
2280 / 1085
2280 / 1085
Comp’t “E” ≤ 400"
lb/amp
2600 / 1240
2600 / 1240
Comp’t “E” 401-442" lb/amp
2800 / 1240
2800 / 1240
Max Battery Size
Comp’t “C”
in
16.25x38.69x31
16.25x38.69x31
Comp’t “D”
in
18.00x38.69x31
18.00x38.69x31
Comp’t “E”
in
20.75x38.69x31
20.75x38.69x31
General Information
Dimensions
Performance
Chassis
Battery
*
Contact factory. Capacity may be subject to derating at height.
** Add 2" with optional sideshift.
*** 5285S “C” Battery compartment has lift speeds of 5275S
**** Optional maximum lift speeds available on units with the “D” or “E” Battery Compartment.
† 442" Lift Height
†† Maximum Performance System optional on 5275S.
