ASG Jergens 65544 AC-1155 - Manual

ASG, Division of Jergens, Inc.
Jergens Way, 15700 South Waterloo Road
Cleveland, Ohio 44110-3898
US Contact Toll-free: (888) 486-6163 • Local: (216) 486-6163 • Fax: (216) 481-4519
Email: [email protected]
Item # 65544, Model AC-1155 AC-Series Series Value-Engineered Direct Plug-In Screwdriver
QUOTE
Model AC-1155 AC-Series Series Value-Engineered Direct Plug-In Screwdriver
• 8.6 to 47 lbf.in
• 110 VAC
• Push-to-Start or Lever/Push-to-Start
• Standard to medium torque applications
• #1 to #10 screws (2.0 mm to 6.0 mm)
• Anti-tamper torque cover standard
• ESD certified housing-surface resistivity of 4 ohms
• Contact ASG for 220V tools
· SPECIFICATIONS · CLASSIFICATION
SPECIFICATIONS
Model No.
AC-1155
Drive Size
1/4 in. hex
Driver Type
Inline
Operation
Lever Start
Push to Start
Torque
8.6 to 47 lbf·in
1.0 to 5.5 N·m
10 to 55 kgf·cm
Approximate RPM
400
Length
10.5 in
Dia.
1.6 in
Weight
27 lb
Voltage (AC) 1
110 V
