Item # 64134, Model SS-6500 SS-Series Special Application DC Screwdriver
QUOTE
Model SS-6500 SS-Series Special Application DC Screwdriver
SS-Series
• Use for sensitive assemblies such as hard drives, LCD's, high density boards
• #10 screws (5.0 mm) and smaller
• Full torque while tool is in reverse makes these tools ideal for rework applications
• Unique ergonomic clutch delivers less torque reaction to operator
• Tamper-resistant torque nut standard on Models SS-6500 &SS-7000; optional on SS-3000 &SS-4000 Models.
• 6 ft detachable cord.
Shock-Absorbing Screwdrivers
• 80% less impact
• Less torque reaction
• 0.17 to 17.5 lbf·in
• 1/4 in. hex or 4.0 mm drive
• Lever start
• Available in small, medium and standard size tools
Shockwave Comparison (SS to 6500)
• Shockwave to type record analyzing device
• Acceleration sensor
• Red line: SS Screwdriver
• Black line: CL to Series Screwdriver
Light Spring Type
• Yellow
Heavy Spring Type
• Yellow
· SPECIFICATIONS · CLASSIFICATION
SPECIFICATIONS
Model No.
SS-6500
Drive Size
1/4 in. hex
Driver Type
Inline
Operation
Lever Start
Torque
2.2 to 11.0 lbf·in
0.25 to 1.3 N·m
2.5 to 13 kgf·cm
Approximate RPM
900 @ 30VDC
600 @ 20VDC
Length
9.0 in
