ASG Jergens 65197 WCBR Wireless Smart Receiver Box User Manual
Wcbr wireless smart receiver box, Classification, For use with
ASG, Division of Jergens, Inc.
Jergens Way, 15700 South Waterloo Road
Cleveland, Ohio 44110-3898
US Contact Toll-free: (888) 486-6163 • Local: (216) 486-6163 • Fax: (216) 481-4519
Email: [email protected]
Item # 65197, WCBR Wireless Smart Receiver Box
QUOTE
WCBR Wireless Smart Receiver Box
The WCBR Wireless Smart Receiver Box monitors several tools at a time. Connects to PC via mini USB cable (not
included) as power source and for data download to PC.
REQUIRED COMPONENT:
• For use with ASG ST Series Smart Transducer Wireless Smart Control Module (65201)
• For use with ASG DTW Series Digital Torque Wrenches, wireless models (See DTW Series Digital Torque Wrenches
with -W model designation)
·
SPECIFICATIONS
·
CLASSIFICATION
·
FOR USE WITH:
SPECIFICATIONS
Model No.
WCBR
Power
Mini USB Cable to PC
CLASSIFICATION
Product Group
Industrial
Real Time or Downloadable Output?
Downloadable
Real Time
Category
Ultimate Gold
World Class Quality
ESD Safe
No
FOR USE WITH:
4/13/2014 | Page 1 of 2
