PV520A User’s Manual
19
Press "
" button, the system will automatically adjust the clock, phase,
H-position and V-position values for optimal settings.
ADVANCE AUTO TUNE PATTERN PROGRAM USING GUIDE
•
As some VGA Card doesn't match the VESA standard. It can't out-put 0.7 V p-p VESA
standard. Therefore, we need "ADVANCE AUTO TUNE PATTERN PROGRAM" to
modify the parameters of monitor to match different output level of VGA card.
•
Win_pat.exe (This file includes in the folder "driver" of CD Title "Interactive User's
Manual") is used for Windows95 or 98 currently display mode adjustment. It will adjust
the VGA input level and video quality to optimize.
•
Dos_pat.exe (This file includes in the folder "driver" of CD Title "Interactive User's
Manual") is used for 720x400 70Hz & 640x 350 70Hz under DOS mode adjustment. It
will adjust the VGA input level and video quality to optimize.
•
For the adjustment, please execute the program, then processing the "Auto Tune"
function in the OSD menu.
2. Color
You can choose either the 6500°K, 9300°K colour temperature mode or User
mode to store your user defined color settings.
User Mode
