NISSAN 2010 Versa Hatchback - Quick Reference Guide - Manual (Page 8)

6
01
02 03 05 04
06
07
08
12
10
11
13
15
14
09
04 DEFROSTING/DEMISTING FRONT AND SIDE WINDOWS
Move the air intake lever 07
to the left position for fresh air.
Turn the air flow control dial 03
to the front window defroster mode .
Turn the temperature control dial 02
left or right to set the desired temperature.
To set the defroster on high, turn both the fan speed control dial 01
and the temperature
control dial 02
, all the way to the right.
The A/c will automatically turn on for enhanced defrosting/demisting performance. The
A/c indicator light will not illuminate.
05 REAR WINDOW DEFROSTER
Push the rear window defroster switch on. Push the switch again to manually turn the
defroster off. This function automatically turns off after approximately 15 minutes.
06 A/C ON/OFF BUTTON (if so equipped)
Press the A/C button to manually turn the A/c on or off.
07 AIR INTAKE LEVER
Move the air intake lever to the
position to draw in fresh outside air.
Move the air intake lever to the
position to recirculate air inside the vehicle.
Move the air intake lever to the
position for maximum cooling when using the
air conditioner (if so equipped).
FM/AM/XM ® * RADIO WITH CD PLAYER (if so equipped)
01 MUTE BUTTON
Press the MUTE button to mute the audio sound. Press again to resume the audio sound.
02 FM/AM BUTTON
Pressing the FM/AM button will change the band to either AM, fM1 or fM2 radio stations.
