2010 Nissan Towing Guide
25
Passenger Vehicles – The towing capacity for Altima (Coupe, Hybrid, and Sedan), Maxima,
and Sentra vehicles is 1,000 lbs.; the maximum trailer tongue load is 100 lbs. DO NOT tow a
trailer with 370Z (Coupe and Roadster), cube, GT-R, or Versa.
NOTE – For passenger vehicles, the trailer tongue load must be subtracted from the GVWR
as shown on the F.M.V.S.S. certification label located in the driver’s-side door area.
2010 XTERRA TOWING DATA
Engine Type
4.0L V6
Transmission
A/T & M/T
Model(s)
2WD & 4WD
Maximum Trailer Weight
1
(lbs.)
5,000
Maximum Trailer Tongue Load
1
(lbs.)
500
Gross Combined Weight Rating (lbs.)
9,656
Maximum Trailer Frontal Area
60 sq. ft.
1 Maximum Trailer Weight values are calculated assuming a base vehicle with driver and
any options required to achieve the rating. Additional passengers, cargo and/or optional
equipment will add weight to the vehicle and reduce your vehicle’s maximum towing
capacity and trailer tongue load.
2 The Maximum Trailer Weight when using the Genuine Nissan step bumper in this
application as a ball mount is 3,500 lbs.; the Maximum Trailer Tongue Load is 350 lbs.
3
Use of a weight-distributing hitch system is recommended when towing over 5,000 lbs.
4 The vehicle tow package does not include a ball mount. Ball mount options are available
through your Nissan dealer:
Class III hitch ball mount for trailers with a Maximum Trailer Weight of 5,000 lbs.
or less.
NOTE – A hitch ball is not included with the Class III ball mount.
Class IV weight-distributing hitch ball mount for trailers with a Maximum Trailer
Weight greater than 5,000 lbs. This ball mount can also be used with trailers
under 5,000 lbs. Maximum Trailer Weight.
NOTE – The Class IV ball mount includes a 2
5
/
16
” hitch ball rated for 10,000 lbs.
NOTES:
Most states require a separate braking system on trailers with a loaded weight
above a specific amount. Check local ordinances.
A/T – Automatic Transmission, CVT – Continuously Variable Transmission
