Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
4 10A Four Wheel Drive Control Module,
Cluster (Restraints Control
Warning)
5 5A ABS Unit (EVAC & FILL), ASC
Unit, Restraints Control Module,
ASC Main SW to ASC Unit
6 10A Flasher Unit, Left reversing Lamp,
Right Reversing Lamp
7 10A Passive Anti-theft Transceiver
(PATS), Restraints Control
Module
8 10A Cluster, Shift Lock Relay (coil),
O/D signal to PCM
9 3A PCM Relay (coil), Fan Relay 1, 2,
3 (coil), A/C Relay (coil)
10 20A Front Wiper Motor, Front Washer
Motor, INT Relay
11 10A IGN Relay (coil), ACC Relay
(coil), Starter Relay (coil), Key
Interlock Solenoid, GEM
12 5A Radio, Clock
13 — Not Used
14 20A Cigar Lighter
15 15A Left Front Position Lamp, Right
Front Position Lamp, Left License
Lamp, Right License Lamp, Left
Tail Lamp, Right Tail Lamp, Park
Lamp Relay (coil), Trailer Fuse,
Illumination Fuse
16 10A Cluster, Power Mirror, GEM
17 15A Sun Roof Motor
