FORD 2002 Ranger v.2 - Manual (Page 272)

Fluid Ford Part
Name Application Capacity
Rear axle
lubricant
5
Motorcraft
SAE 80W-90
Premium Rear
Axle Lubricant All 2.4-2.5L
(5.0-5.3 pints)
Windshield
washer fluid Ultra-Clear
Windshield
Washer
Concentrate All 2.6L
(2.75 quarts)
1 Ensure the correct automatic transmission fluid is used. Transmission
fluid requirements are indicated on the dipstick or on the dipstick
handle. MERCON
௡ and MERCON௡ V are not interchangeable. DO NOT
mix MERCON
௡ and MERCON௡V. Refer to the scheduled maintenance
guide to determine the correct service interval.
2 Indicates only approximate dry-fill capacity. Some applications may vary
based on cooler size and if equipped with an in-tank cooler. The amount
of transmission fluid and fluid level should be set by the indication on
the dipstick’s normal operating range.
3 Service refill capacity for the manual transmission is determined by
filling the transmission to the bottom of the filler hole with the vehicle
on a level surface.
4 Add the coolant type originally equipped in your vehicle.
5 Traction-Lok axles use 2.2–2.4L (4.75–5.0 pints) of rear axle lubricant.
Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or
equivalent meeting Ford specification EST-M2C118–A for complete refill
of Traction-Lok axles.
Service refill capacities are determined by filling the rear axle 6 mm to
14 mm (1/4 inch to 9/16 inch) below the bottom of the filler hole.
Maintenance and Specifications
272
