Page 221

Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
12
2A**
Brake pressure switch
13
15A**
Daytime Running Lamps (DRL)
14
—
Not used
15
15A**
IDM logic (Diesel engine only)
16
—
Not used
17
10A**
A/C clutch
18
10A**
IDM relay (Diesel engine only)
19
—
Not used
20
10A**
Trailer tow back-up lamps
21
—
Not used
22
60A***
ABS (Coils)
23
60A***
ABS (Pump)
201
1
⁄
2
ISO relay
Trailer tow right turn signal/stop
lamp
202
1
⁄
2
ISO relay
Trailer tow left turn signal/stop
lamp
203
1
⁄
2
ISO relay
A/C clutch
204
—
Not used
205
1
⁄
2
ISO relay
DRL #1
206
1
⁄
2
ISO relay
DRL #2
301
Full ISO relay
DRL #3
302
Full ISO relay
HFCM
303
Full ISO relay
Blower
304
High-current
relay
IDM (Diesel engine only)
* Cartdrige Fuse ** Mini Fuses *** Maxi fuse
JUMP STARTING YOUR VEHICLE
The gases around the battery can explode if exposed to flames,
sparks, or lit cigarettes. An explosion could result in injury or
vehicle damage.
REVIEW COPY
2005 F250/350/450/550 (f23), Owners Guide (post-2002-fmt) (own2002),
Market: USA_English (fus)
Roadside Emergencies
221
