Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse Panel
Description
25 10A* LH low beam headlamp
26 20A* Horn relay (PCB3), Horn power
27 5A* Passenger Air bag Deactivation (PAD)
warning lamp, Cluster air bag warning
lamp, Cluster RUN /START power
28 5A* SecuriLock transceiver (PATS)
29 15A* PCM 4x4 power
30 15A* PCM 4x4 power
31 20A* Radio power
32 15A* Vapor Management Valve (VMV), A/C
clutch relay, Canister vent, Heated
Exhaust Gas Oxygen (HEGO) sensors #11
and #21, CMCV, Mass Air Flow (MAF)
sensor, VCT, Heated Positive Crankcase
Ventilation (PCV) valve (4.2L engine), CID
sensor (4.2L engine)
33 15A* Shift solenoid, CMS #12 and #22
34 20A* Fuel injectors and PCM power, Intake
Manifold Runner Control (4.2L engine)
35 20A* Instrument cluster high beam indicator,
High beam headlamps
36 10A* Trailer tow right turn/stop lamps
37 20A* Rear power point
38 25A* Subwoofer power
39 20A* Instrument panel power point
40 20A* Low beam headlamps, DRL
41 20A* Cigar lighter, Diagnostic connector power
42 10A* Trailer tow left turn/stop lamps
101 30A** Starter solenoid
102 20A** Ignition switch feed
103 20A** ABS valves
104 — Not used
