Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse Panel
Description
8 — Not used
9 30A** Power door locks, Power seats
10 15A* Heated mirrors
11 15A* Sunroof
12 5A* Radio
13 — Not used
14 — Not used
15 30A** Power windows
16 15A* Subwoofer
17 15A* Low beams
18 10A* 4WD
19 — Not used
20 15A* Horn
21 10A* Rear wiper motor, Rear wiper washer
22 10A* Electrochromatic mirror, Instrument cluster
23 — Not used
24 20A* Cigar lighter
25 20A* Front wiper motor, Front wiper washer
26 5A* Climate control system mode switch
27 5A* Canister vent, Speed control cancel switch
28 10A* Instrument cluster
29 10A* Reverse park aid
30 — Not used
31 — Not used
32 10A* Brake-Transmission shift lock
33 15A* Air bag module, Passenger Air bag
Deactivation (PAD) indicator lamp,
Occupant Classification Sensor (OCS)
34 5A* ABS module, Evac and Fill, Speed control
35 5A* Heated seats module, 4WD
* Mini fuse ** Cartridge fuse
REVIEW COPY
2005 Escape (204), Owners Guide (post-2002-fmt) (own2002),
Market: USA_English (fus)
Roadside Emergencies
213
