Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
5 10A Speed control deactivation switch,
Stop signal, Brake-Transmission
Shift Interlock (BTSI)
(column-shift transmission)
6 10A Ignition (ON) - Cluster
7 10A LCM (Park lamps, Switch
illumination)
8 10A Ignition (ON) - Rear Air
Suspension Module (RASM),
Variable Assist POwer Steering
(VAPS)
9 20A LCM (Headlamps, Cornering
lamps)
10 5A Ignition (ON/START) - Driver’s
Door Module (DDM), Police PDB
(Police vehicles only)
11 10A Ignition (START) - ON/ACC
(window) relay coil (non-Police
vehicles only)
Ignition (START) - ON/ACC
(window and decklid) relay coil
and Police ON/ACC relay coil
(Police vehicles only)
12 10A Ignition (ON/START) - Starter
relay coil, DTRS
13 10A Ignition (START) - Wiper module
14 10A Ignition (ON) - BTSI (Floor-shift
transmission)
15 7.5A Ignition (START) - LCM, Door
lock switch illumination, Heated
seat switch illumination,
Moonroof, Overhead console,
Electrochromatic mirror
REVIEW COPY
2005 Crown Victoria (cro), Owners Guide (post-2002-fmt) (own2002),
Market: USA_English (fus)
Roadside Emergencies
182
