Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
25 10A* LH low beam headlamp
26 20A* Horn relay (PCB3), Horn power
27 5A* Passenger Air bag Deactivation
(PAD) warning lamp, Cluster air bag
warning lamp, Cluster RUN /START
power
28 5A* SecuriLock transceiver (PATS), PCM
IGN monitor
29 15A* PCM 4x4 power
30 15A* PCM 4x4 power
31 20A* Radio power
32 15A* Vapor Management Valve (VMV), A/C
clutch relay, Canister vent, Heated
Exhaust Gas Oxygen (HEGO)
sensors #11 and #21, CMCV, Mass Air
Flow (MAF) sensor, VCT, Heated
Positive Crankcase Ventilation (PCV)
valve (4.2L engine), CID sensor (4.2L
engine), 4.6L/4.2L EGR
33 15A* Shift solenoid, CMS #12 and #22,
Ignition coils
34 15A* PCM power
35 20A* Instrument cluster high beam
indicator, High beam headlamps
36 10A* Trailer tow right turn/stop lamps
37 20A* Rear power point
38 25A* Subwoofer power
39 20A* Instrument panel power point
40 20A* Low beam headlamps, DRL
41 20A* Cigar lighter, Diagnostic connector
power
42 10A* Trailer tow left turn/stop lamps
