23 107434
OWNER’S MANUAL
For more information, visit www.desatech.com
PARTS LIST
S39NT
This list contains replaceable parts used in your heater. When ordering parts, follow the instructions
listed under Replacement Parts on page 24 of this manual.
KEY
NO.
PART NO. DESCRIPTION QTY.
1 107085-01CK Top Panel, Stove 1
2 107077-01CK Pedestal Stove Assembly 1
3 107076-01CK Stove Base 1
4 107075-01CK Stove Back Panel 1
5 107082-01CK Top Trim 1
6 105657-01 Blower Bracket 2
7 107363-01CK Door 1
8 107078-01CJ Firebox Back Panel 1
9 107080-01CK Firebox Floor 1
10 107081-01CJ Firebox Top 1
11 107365-01CK Screen Assembly 1
12 101382-01 Valve Bracket 1
13 107092-01 Brass Trim, Bottom 1
14 107093-01 Brass Trim, Firebox 1
15 105576-01 Knob 1
16 101386-02 Door Hinge 2
17 099230-02 Shoulder Screw 4
18 107079-01CJ Heat Deflector 1
19 102455-12 Louver, Small 2
20 102455-13 Louver, Large 1
21 107091-01CK Support, End Louver 2
22 107084-01CK Support, Center Louver 2
23 101514-01CK Blower Sensor Cover 1
24 103158-01 Magnet Catch 1
25 107083-01 Magnet Bracket 1
26 098304-03 Louver Screw 12
PARTS AVAILABLE — NOT SHOWN
101054-01 Lighting Instructions Plate 1
100563-01 Warning Plate 1
104310-12 Information Video 1
104108-06 Touch-Up Paint Kit 1
