Rear Power Distribution Center Fuses
Cavity
Fuse
Circuits
1
60 Amp
Yellow
Ignition Off Draw (IOD)
2
40 Amp
Green
Battery
3
—
—
4
40 Amp
Green
Battery
5
30 Amp
Pink
Heated Seats - if equipped
6
20 Amp
Yellow
Fuel Pump
7
—
—
8
15 Amp
Blue
Ignition Switch/Occupant
Classification Module (OCM)
9
20 Amp
Yellow
Console Power Outlet
10
—
—
Cavity
Fuse
Circuits
11
25 Amp
C/BRKR
Cluster - without power
memory seat/Driver Seat
Switch - with power memory
seat/Memory Module - if
equipped
12
25 Amp
C/BRKR
Passenger Seat Switch
13
25 Amp
C/BRKR
Door Modules - except base/
Driver Door Lock Switch -
base/Driver Express Power
Window Switch - if equipped/
Passenger Door Lock Switch -
base
14
10 Amp
Red
AC Heater Control/Cluster/
Sentry Key Remote Keyless
Entry
15
20 Amp
Yellow
Trailer Tow Brake Module - if
equipped
16
—
—
17
20 Amp
Yellow
Cluster
