Fuse/Relay
Location
Fuse Amp
Rating
Passenger Compartment Fuse
Panel Description
1 — Not used
2 — Not used
3 15A* Front and rear park lamps
4 10A* Ignition switch
5 2A* Powertrain Control Module (PCM
relay), PATS module
6 15A* Stop lamps
7 10A* Instrument cluster, Power mirror
switch, Radio
8 — Not used
9 30A** Power door locks
10 15A* Heated mirrors, Rear defroster
switch indicator
11 15A* Moon roof
12 5A* Radio
13 — Not used
14 — Not used
15 30A** Power windows
16 15A* Subwoofer
17 15A* Low beams
18 10A* 4x4
19 — Not used
20 15A* Horn
21 10A* Rear wiper motor, Rear wiper
washer
22 10A* Instrument cluster
23 — Not used
24 20A* Cigar lighter
25 20A* Front wiper motor, Front wiper
washer
26 5A* Climate control system mode
switch
2007 Escape Hybrid (ehv)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
228
