Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
6
40A*
ABS module (Pump)
7
30A*
Upfitter auxiliary switch #1
8
30A*
Upfitter auxiliary switch #2
9
40A*
ABS module (Coil)
10
20A*
Cigar lighter
11
20A*
Instrument panel power point
12
15A**
Brake On/Off (BOO) relay feed
13
5A **
Brake switch, Brake switch relay
coil, SJB module, 4x4 module
14
—
Not used
15
—
Not used
16
Relay
A/C clutch
17
Relay
Wipers
18
Relay
Fuel Pump Driver Module
(FPDM), Fuel injectors (Gasoline
engines), Diesel Fuel Control
Module (DFCM) (Diesel engine)
19
Relay
Back-up lamps, Reverse Sensing
System (RSS), Engine
compartment fuse 63
20
Relay
Trailer stop/turn (Left)
21
Relay
Trailer stop/turn (Right)
22
Relay
Stop lamps, Center
High-Mounted Stop Lamp
(CHMSL), TBC, Customer access
23
15A**
Heater mirror, Heated spotted
mirror
24
40A*
Blower motor relay
25
—
Not used
26
30A*
ESOF relay lo-hi
27
50A*
Glow Plug Control Module
(GPCM) #1 (Diesel engine only)
28
20A*
Heated mirror relay
