Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
5 5A Moonroof, Power down back
window, Door lock switch
illumination, Rearview mirror with
microphone
6 20A Door unlock/lock
7 15A Trailer tow stop/turn lamps
8 15A Ignition switch power, PATS,
Cluster
9 2A 6-speed transmission/PCM
(Ignition RUN/START), Fuel
pump relay
10 5A Front wiper RUN/ACC (relay in
PDB)
11 5A Radio start
12 5A Radio, Trailer tow battery charge
(relay in PDB)
13 15A Heated mirror
14 20A Horn
15 10A Reverse lamps
16 10A Trailer tow reverse lamps
17 10A RCM (restraints), Passenger
occupancy
18 10A IVD switch, IVD, 4x4 module, 4x4
switch, Heated seat switches,
Compass, Electrochromatic
mirror, Reverse park aid
19 — Not used
20 10A Manual climate control, DEATC,
Brake shift
21 — Not used
22 15A Brake switch, Stop lamps, Turn
lamps
