Roadside emergencies – FORD 2009 E-450 v.1 User Manual
Page 231
Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
42
15A
Diagnostic connector (stripped
chassis)
43
20A*
Fuel pump
44
10A*
Upfitter #3
45
15A*
Upfitter #4
46
10A*
PCM keep alive power, Canister
vent, PCM relay coil
47
40A**
ABS coil
48
20A**
Trailer tow stop lamp/turn signal
49
30A**
Wiper motor
50
—
Not used
51
20A**
Cutaway
52
10A*
Stripped chassis and modified
vehicle run/start relay coil
53
10A*
ABS run/start feed
54
10A*
Fuel pump relay coil (gas engine
only)
55
10A*
ECM (diesel engine only)
56
20A*
DFCM (diesel engine only)
57
20A*
Trailer tow park lamp
58
15A*
Trailer tow backup
59
—
Not used
60
—
One Touch Integrated Start
(OTIS) (diode)
61
—
Auxiliary battery (diode)
62
Micro relay
Upfitter #2
63
30A**
Trailer tow battery charge
64
—
Not used
65
20A**
Power point 2 (glove box)
66
20A**
Power point 3 (left-hand B-pillar)
67
20A**
Power point 1 (instrument panel)
68
50A**
Modified vehicle
2009 Econoline (eco)
Owners Guide, 1st Printing
USA (fus)
Roadside Emergencies
231
