transmission has been turned off and the grade assist function has been
turned on, refer to the Driving chapter.
Low tire pressure warning:
Illuminates when your tire pressure
is low. If the light remains on at
start up or while driving, the tire
pressure should be checked. Refer
to Inflating your tires in the Tires, Wheels and Loading chapter. When
the ignition is first turned to on, the light will illuminate for three
seconds to ensure the bulb is working. If the light does not turn on or
begins to flash, contact your authorized dealer as soon as possible. For
more information on this system, refer to Tire pressure monitoring
system (TPMS) in the Tires, Wheels and Loading chapter.
Speed control: The speed control
system uses two different–colored
indicator lights to indicate what
mode the system is in:
• On (amber light): Illuminates
when the speed control system is turned on. Turns off when the speed
control system is engaged or turned off.
• Engaged (green light): Illuminates when the speed control system is
engaged. Turns off when the speed control system is disengaged.
Door ajar: Illuminates when the
ignition is in the on position and any
door or decklid is open.
Anti-theft system: Flashes when
the SecuriLock
௡ passive anti-theft
system has been activated.
Throttle control/transmission:
Illuminates when a powertrain or a
AWD fault has been detected. If the
indicator stays on or continues to
come on, contact your authorized
dealer for service as soon as possible.
Turn signal: Illuminates when the
left or right turn signal or the
hazard lights are turned on. If the
indicators flash faster, check for a burned out bulb.
