Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
15
10A**
Intercooler pump relay (Shelby
only)
16
20A**
Heated seats
17
10A**
Alternator sense
18
20A*
Auxiliary body module (ABM)
19
30A*
Starter relay
20
30A*
Rear amplifier (Shaker 1000
radio)
21
30A*
Powertrain relay
22
20A*
Powerpoint (instrument panel)
23
10A**
Powertrain control module (PCM)
keep-alive power
24
10A**
Brake on/off (BOO) power
25
10A**
A/C compressor relay
26
20A**
Left high intensity discharge
headlamp relay
27
20A**
Right high intensity discharge
headlamp relay
28
—
Not used
29
30A*
Passenger front window
30
—
Not used
31
30A*
Passenger power seat
32
30A*
Driver power seat
33
30A*
Front amplifier (Shaker 500
radio)
34
30A*
Driver front window motor
35
40A*
Convertible top motor
36
Diode
Fuel diode
37
—
Not used
38
15A**
Fuel injectors (Shelby only)
39
5A**
Rear defroster coil (run/start)
